Analog Devices Inc. EV1HMC882ALP5 Evaluation Board
Analog Devices EV1HMC882ALP5 Evaluation Board evaluates all the features of the HMC882ALP5E. The EV1HMC882ALP5 has Subminiature Version A (SMA) connectors to apply cutoff frequency control voltage (VFCTL). The board also has SRI-type Subminiature Version A (SMA) connectors for the RF input and output. The cutoff frequency can be adjusted by varying VFCTL from 0V to 14V.
Features
- Single control voltage (VFCTL)
- Simple board design with a minimal component requirement
Related Products
Analog Devices Inc. HMC882A Monolithic Microwave Integrated Circuit
A low-pass filter that features a user-selectable cutoff frequency (f3dB).
Published: 2019-03-12
| Updated: 2023-08-14
